What style of lift kit do I have?

Spring Lift, Spacer Lift, or Leveling Kit
[1 to 3.5-inch lift]

Spacer Lift or Leveling Kit - These kits cause the upper arms to angle downward toward the ball joints. The Leveling kit or strut lift removes the factory rake angle by lifting the front level with the vehicle's rear suspension.

  • Coil Spring spacer
  • On-top strut spacers
  • Preload Collar
  • Bilstein 5100 Series, adjustable struts
  • Bilstein 6100 Series, adjustable struts
  • Using lift springs on struts
  • Higher-rate strut springs
  • Adjustable coil over struts

Spring lift kit - These kits cause the upper arms to angle downward toward the ball joints. Spring kits remove the factory rake angle and lift the rear of the vehicle about 1.5" - 2.5".

  • Coil Spring spacer
  • On-top strut spacers
  • Preload Collar
  • Bilstein 5100 Series, adjustable struts
  • Bilstein 6100 Series, adjustable struts
  • Using lift springs on struts
  • Using higher-rate strut springs
  • Adjustable coil over struts




Cradle Drop, Cross-Member Drop, or Drop Bracket Lift Kit
[4 to 12-inch lift]

Cradle Drop Kit - These kits keep the upper arms level like the factory stock suspension.
cradle drop lift, cross-member drop, or drop bracket lift kit

  • This style kit relocates the lower control arms on the front of the vehicle using a drop bracket. These brackets offset the lower control mounting holes by 4", 6", or 8". These kits also include longer steering knuckles to fit within the bigger gap between the upper and the lower ball joints.




Cradle Drop Kit with Spring Lift
[6 to 12-inch lift]

Cradle Drop Kit - These kits cause the upper arms to angle downward toward the ball joints. cradle drop lift, cross-member drop, or drop bracket lift kit

  • This style kit relocates the lower control arms on the front of the vehicle by using a drop bracket. These brackets offset the lower control mounting holes by 4", 6", or 8". These kits also include longer steering knuckles to fit within the bigger gap between the upper and the lower ball joints.

Spring lift kit - Spring kits on the front struts

  • Coil Spring spacer
  • On-top strut spacers
  • Preload Collar
  • Bilstein 5100 Series, adjustable struts
  • Bilstein 6100 Series, adjustable struts
  • Using lift springs on struts
  • Higher-rate strut springs
  • Adjustable coil over struts

Example: 4" cradle drop lift with a 2" spring/coil over lift = 6" lift kit.  6" cradle drop lift with a 2" spring/coil over lift = 8" lift kit. When the mounting holes are offset by 4" and the kit is a 6" kit, the other 2 inches are made up from the strut lift or spring lift.
