GX460 2010-2023

Select Your Vehicle

Year

Make

Model

PRE-ASSEMBLED KIT

Spring Lift or Leveling Kit [1 to 3.5-inch lift]
Spacer Lift, Leveling kit, and Spring lift kit

These kits cause the upper arms to angle downward toward the ball joints. The Leveling kit or strut lift removes the factory rake angle by lifting the front level with the rear of the vehicle.

Spring kits remove the factory rake angle and lift the rear of the vehicle about 1.5" - 2.5"

Spring Lift with Cradle Drop Kit
Spring lift kit with Cradle Drop Kit

These kits cause the upper arms to angle downward toward the ball joints. The cradle drop lift, cross-member drop, or drop bracket lift kit with spring kits.

Example: 4" cradle drop lift with a 2" spring/coil over lift = 6" lift kit. 6" cradle drop lift with a 2" spring/coil over lift = 8" lift kit. When the mounting holes are offset by 4" and the kit is a 6" kit, the other 2 inches are made up from the strut lift or spring lift.

JBA STD High Caster Upper Control Arms for Lexus GX470, Lexus GX460 2003-2023 (1 to 3.5 inch lift)

$558.00
PRE-ASSEMBLED KIT
Cradle Drop Kit [4 to 12-inch lift]
Cradle Drop Kit

Like the factory stock suspension, these kits keep the upper arms level. cradle drop lift, cross-member drop, or drop bracket lift kit

This style kit relocates the lower control arms on the front of the vehicle using a drop bracket. These brackets offset the lower control mounting holes by 4", 6", or 8". These kits also include longer steering knuckles to fit within the bigger gap between the upper and the lower ball joints.
JBA UCAs for Toyota Tacoma, 4Runner, FJ Cruisers, Lexus GX470, Lexus GX460 2003-2023 (4 to 12 inch lift)

$790.00
PRE-ASSEMBLED KIT

Spring Lift or Leveling Kit [1 to 3.5-inch lift]
Spacer Lift, Leveling kit, and Spring lift kit

These kits cause the upper arms to angle downward toward the ball joints. The Leveling kit or strut lift removes the factory rake angle by lifting the front level with the rear of the vehicle.

Spring kits remove the factory rake angle and lift the rear of the vehicle about 1.5" - 2.5"

Spring Lift with Cradle Drop Kit
Spring lift kit with Cradle Drop Kit

These kits cause the upper arms to angle downward toward the ball joints. The cradle drop lift, cross-member drop, or drop bracket lift kit with spring kits.

Example: 4" cradle drop lift with a 2" spring/coil over lift = 6" lift kit. 6" cradle drop lift with a 2" spring/coil over lift = 8" lift kit. When the mounting holes are offset by 4" and the kit is a 6" kit, the other 2 inches are made up from the strut lift or spring lift.

JBA HD High Caster Upper Control Arms for Toyota Tacoma, 4Runner, FJ Cruisers, Lexus GX470, Lexus GX460 (1 to 3.5 inch lift)

$790.00

A Summary of the Benefits

1

Ball joints are mounted on an angle to line up with steering knuckle
No more premature ball joint failure!
2

Replaceable ball joints
You can replace the ball joint for under $70.00 per control arm.
3

Factory front end alignment
No premature tire wear.
4

Red powder coat finish
Your friends can see you invested in custom arms for your vehicle
5

Heavy duty tubing
Long lasting off road durability.
6

CNC manufactured parts
Precision and consistent parts every time!
7

Manufactured in USA
Made by Americans for ALL!!
8

3 degrees additional caster
Impove alignmnent through additional added positive caster

Elevate Your Lexus-GX460 Experience with JBA Offroad Upper Control Arms

Are you an off-road enthusiast who owns a lifted Lexus GX460? If so, we have something that will take your off-roading experience to the next level. We're talking about the Lexus GX460 Upper Control Arms made by JBA Offroad.

Understanding the Importance of Upper Control Arms
UCAs, or Upper Control Arms, are a crucial part of your vehicle's suspension system, connecting the vehicle's frame to its wheel hub. They play a pivotal role in ensuring stability and a smooth ride, especially when navigating challenging terrains.

Elevate Your Off-Roading Experience with JBA Offroad's Lexus GX460 UCAs
For those looking to enhance the performance of their lifted Lexus GX460, upgrading to JBA Offroad's Lexus GX460 Upper Control Arms is a no-brainer. Here's why:

High Caster Design
JBA Upper Control Arms feature a high caster design that improves stability and steering wheel self-centering. This means whether you're cruising on the highway or exploring rough terrains, you'll experience a smoother, more controlled ride.

Superior Range of Motion
Thanks to the JBA Ball Joint’s 90 degrees range of motion, you can tackle even the toughest off-road terrain with ease. That's the widest range of motion you'll find on the market today!

Advanced Bushing Technology
At the heart of JBA Upper Control Arms lies the patented JBA EZ Lube Bushings (U.S. Patent No. 11,293,511). These innovative bushings feature grease ports and pressure relief valves, which keep the outer face lubricated, thereby increasing performance, durability, and lifespan.

High-Quality Construction
Constructed from 1026 DOM A513-5 Domestic Tubing and coated with Cerakote clear coating, JBA Upper Control Arms offer superior durability and rust resistance.

Easy Installation
One of the standout features of JBA Upper Control Arms is their ease of installation. They come pre-assembled and are ready to bolt onto your vehicle. The entire installation process is estimated to take between 1-3 hours, making it a quick and straightforward upgrade.

The JBA Offroad Advantage
When you invest in JBA Upper Control Arms, you're not just buying a product; you're investing in peace of mind. JBA offers a lifetime warranty on the structural integrity of their Upper Control Arms and a one-year warranty on ball joints, bushings, and powder coating.

So, if you're looking to enhance your lifted Lexus GX460's off-road capabilities and enjoy a smoother, more controlled ride, upgrading to JBA Upper Control Arms is the way to go. Visit the JBA Offroad website today to purchase your Upper Control Arms and take your off-roading experience to new heights!

JBA upper control arms for the Lexus GX460 fit model years 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, and 2023.
