PRE-ASSEMBLED KIT
Cradle Drop Kit [4 to 12-inch lift]
Cradle Drop Kit

Like the factory stock suspension, these kits keep the upper arms level. cradle drop lift, cross-member drop, or drop bracket lift kit

This style kit relocates the lower control arms on the front of the vehicle using a drop bracket. These brackets offset the lower control mounting holes by 4", 6", or 8". These kits also include longer steering knuckles to fit within the bigger gap between the upper and the lower ball joints.
JBA HD Upper Control Arms for Toyota Tundra 2022 Plus, Sequoia 2023 Plus (4 to 12 inch lift)

$660.00
PRE-ASSEMBLED KIT
Cradle Drop Kit [4 to 12-inch lift]
Cradle Drop Kit

Like the factory stock suspension, these kits keep the upper arms level. cradle drop lift, cross-member drop, or drop bracket lift kit

This style kit relocates the lower control arms on the front of the vehicle using a drop bracket. These brackets offset the lower control mounting holes by 4", 6", or 8". These kits also include longer steering knuckles to fit within the bigger gap between the upper and the lower ball joints.
JBA Cradle Drop Upper Control Arms for Toyota Tundra 2007-2021, Sequoia 2008-2022, 4 to 12 inch lift

$660.00
PRE-ASSEMBLED KIT

Spring Lift or Leveling Kit [1 to 3.5-inch lift]
Spacer Lift, Leveling kit, and Spring lift kit

These kits cause the upper arms to angle downward toward the ball joints. The Leveling kit or strut lift removes the factory rake angle by lifting the front level with the rear of the vehicle.

Spring kits remove the factory rake angle and lift the rear of the vehicle about 1.5" - 2.5"

Spring Lift with Cradle Drop Kit
Spring lift kit with Cradle Drop Kit

These kits cause the upper arms to angle downward toward the ball joints. The cradle drop lift, cross-member drop, or drop bracket lift kit with spring kits.

Example: 4" cradle drop lift with a 2" spring/coil over lift = 6" lift kit. 6" cradle drop lift with a 2" spring/coil over lift = 8" lift kit. When the mounting holes are offset by 4" and the kit is a 6" kit, the other 2 inches are made up from the strut lift or spring lift.

JBA HD HC Upper Control Arms for Toyota Tundra 2022 Plus, Sequoia 2023 Plus (1 to 3.5 inch lift)

$660.00
PRE-ASSEMBLED KIT

Spring Lift or Leveling Kit [1 to 3.5-inch lift]
Spacer Lift, Leveling kit, and Spring lift kit

These kits cause the upper arms to angle downward toward the ball joints. The Leveling kit or strut lift removes the factory rake angle by lifting the front level with the rear of the vehicle.

Spring kits remove the factory rake angle and lift the rear of the vehicle about 1.5" - 2.5"

Spring Lift with Cradle Drop Kit
Spring lift kit with Cradle Drop Kit

These kits cause the upper arms to angle downward toward the ball joints. The cradle drop lift, cross-member drop, or drop bracket lift kit with spring kits.

Example: 4" cradle drop lift with a 2" spring/coil over lift = 6" lift kit. 6" cradle drop lift with a 2" spring/coil over lift = 8" lift kit. When the mounting holes are offset by 4" and the kit is a 6" kit, the other 2 inches are made up from the strut lift or spring lift.

JBA STD High Caster Upper Control Arms for Lexus GX470, Lexus GX460 2003-2023 (1 to 3.5 inch lift)

$558.00
PRE-ASSEMBLED KIT

Spring Lift or Leveling Kit [1 to 3.5-inch lift]
Spacer Lift, Leveling kit, and Spring lift kit

These kits cause the upper arms to angle downward toward the ball joints. The Leveling kit or strut lift removes the factory rake angle by lifting the front level with the rear of the vehicle.

Spring kits remove the factory rake angle and lift the rear of the vehicle about 1.5" - 2.5"

Spring Lift with Cradle Drop Kit
Spring lift kit with Cradle Drop Kit

These kits cause the upper arms to angle downward toward the ball joints. The cradle drop lift, cross-member drop, or drop bracket lift kit with spring kits.

Example: 4" cradle drop lift with a 2" spring/coil over lift = 6" lift kit. 6" cradle drop lift with a 2" spring/coil over lift = 8" lift kit. When the mounting holes are offset by 4" and the kit is a 6" kit, the other 2 inches are made up from the strut lift or spring lift.

JBA STD High Caster Upper Control Arms for Toyota FJ Cruisers (1 to 3.5 inch lift)

$558.00
PRE-ASSEMBLED KIT

Spring Lift or Leveling Kit [1 to 3.5-inch lift]
Spacer Lift, Leveling kit, and Spring lift kit

These kits cause the upper arms to angle downward toward the ball joints. The Leveling kit or strut lift removes the factory rake angle by lifting the front level with the rear of the vehicle.

Spring kits remove the factory rake angle and lift the rear of the vehicle about 1.5" - 2.5"

Spring Lift with Cradle Drop Kit
Spring lift kit with Cradle Drop Kit

These kits cause the upper arms to angle downward toward the ball joints. The cradle drop lift, cross-member drop, or drop bracket lift kit with spring kits.

Example: 4" cradle drop lift with a 2" spring/coil over lift = 6" lift kit. 6" cradle drop lift with a 2" spring/coil over lift = 8" lift kit. When the mounting holes are offset by 4" and the kit is a 6" kit, the other 2 inches are made up from the strut lift or spring lift.

JBA STD High Caster Upper Control Arms for Toyota 4Runner 2003-2024 (1 to 3.5 inch lift)

$558.00
PRE-ASSEMBLED KIT

Spring Lift or Leveling Kit [1 to 3.5-inch lift]
Spacer Lift, Leveling kit, and Spring lift kit

These kits cause the upper arms to angle downward toward the ball joints. The Leveling kit or strut lift removes the factory rake angle by lifting the front level with the rear of the vehicle.

Spring kits remove the factory rake angle and lift the rear of the vehicle about 1.5" - 2.5"

Spring Lift with Cradle Drop Kit
Spring lift kit with Cradle Drop Kit

These kits cause the upper arms to angle downward toward the ball joints. The cradle drop lift, cross-member drop, or drop bracket lift kit with spring kits.

Example: 4" cradle drop lift with a 2" spring/coil over lift = 6" lift kit. 6" cradle drop lift with a 2" spring/coil over lift = 8" lift kit. When the mounting holes are offset by 4" and the kit is a 6" kit, the other 2 inches are made up from the strut lift or spring lift.

JBA STD HC Upper Control Arms for Toyota Tundra '00-'06, Sequoia '01-'07 (1 to 3.5 inch lift)

$570.00
PRE-ASSEMBLED KIT
Cradle Drop Kit [4 to 12-inch lift]
Cradle Drop Kit

Like the factory stock suspension, these kits keep the upper arms level. cradle drop lift, cross-member drop, or drop bracket lift kit

This style kit relocates the lower control arms on the front of the vehicle using a drop bracket. These brackets offset the lower control mounting holes by 4", 6", or 8". These kits also include longer steering knuckles to fit within the bigger gap between the upper and the lower ball joints.
JBA UCAs for Toyota Tacoma, 4Runner, FJ Cruisers, Lexus GX470, Lexus GX460 2003-2023 (4 to 12 inch lift)

$790.00
PRE-ASSEMBLED KIT

Spring Lift or Leveling Kit [1 to 3.5-inch lift]
Spacer Lift, Leveling kit, and Spring lift kit

These kits cause the upper arms to angle downward toward the ball joints. The Leveling kit or strut lift removes the factory rake angle by lifting the front level with the rear of the vehicle.

Spring kits remove the factory rake angle and lift the rear of the vehicle about 1.5" - 2.5"

Spring Lift with Cradle Drop Kit
Spring lift kit with Cradle Drop Kit

These kits cause the upper arms to angle downward toward the ball joints. The cradle drop lift, cross-member drop, or drop bracket lift kit with spring kits.

Example: 4" cradle drop lift with a 2" spring/coil over lift = 6" lift kit. 6" cradle drop lift with a 2" spring/coil over lift = 8" lift kit. When the mounting holes are offset by 4" and the kit is a 6" kit, the other 2 inches are made up from the strut lift or spring lift.

JBA STD High Caster Upper Control Arms for Toyota Tacoma, 4Runner 1996-2004 (1 to 3.5 inch lift)

$570.00
PRE-ASSEMBLED KIT

Spring Lift or Leveling Kit [1 to 3.5-inch lift]
Spacer Lift, Leveling kit, and Spring lift kit

These kits cause the upper arms to angle downward toward the ball joints. The Leveling kit or strut lift removes the factory rake angle by lifting the front level with the rear of the vehicle.

Spring kits remove the factory rake angle and lift the rear of the vehicle about 1.5" - 2.5"

Spring Lift with Cradle Drop Kit
Spring lift kit with Cradle Drop Kit

These kits cause the upper arms to angle downward toward the ball joints. The cradle drop lift, cross-member drop, or drop bracket lift kit with spring kits.

Example: 4" cradle drop lift with a 2" spring/coil over lift = 6" lift kit. 6" cradle drop lift with a 2" spring/coil over lift = 8" lift kit. When the mounting holes are offset by 4" and the kit is a 6" kit, the other 2 inches are made up from the strut lift or spring lift.

JBA HD HC Upper Control Arms for Toyota Tundra 2007-2021, Sequoia 2008-2021, 1 to 3.5 inch lift

$660.00
PRE-ASSEMBLED KIT

Spring Lift or Leveling Kit [1 to 3.5-inch lift]
Spacer Lift, Leveling kit, and Spring lift kit

These kits cause the upper arms to angle downward toward the ball joints. The Leveling kit or strut lift removes the factory rake angle by lifting the front level with the rear of the vehicle.

Spring kits remove the factory rake angle and lift the rear of the vehicle about 1.5" - 2.5"

Spring Lift with Cradle Drop Kit
Spring lift kit with Cradle Drop Kit

These kits cause the upper arms to angle downward toward the ball joints. The cradle drop lift, cross-member drop, or drop bracket lift kit with spring kits.

Example: 4" cradle drop lift with a 2" spring/coil over lift = 6" lift kit. 6" cradle drop lift with a 2" spring/coil over lift = 8" lift kit. When the mounting holes are offset by 4" and the kit is a 6" kit, the other 2 inches are made up from the strut lift or spring lift.

JBA STD High Caster Upper Control Arms for Toyota Tacoma 2005-2023

$558.00
PRE-ASSEMBLED KIT

Spring Lift or Leveling Kit [1 to 3.5-inch lift]
Spacer Lift, Leveling kit, and Spring lift kit

These kits cause the upper arms to angle downward toward the ball joints. The Leveling kit or strut lift removes the factory rake angle by lifting the front level with the rear of the vehicle.

Spring kits remove the factory rake angle and lift the rear of the vehicle about 1.5" - 2.5"

Spring Lift with Cradle Drop Kit
Spring lift kit with Cradle Drop Kit

These kits cause the upper arms to angle downward toward the ball joints. The cradle drop lift, cross-member drop, or drop bracket lift kit with spring kits.

Example: 4" cradle drop lift with a 2" spring/coil over lift = 6" lift kit. 6" cradle drop lift with a 2" spring/coil over lift = 8" lift kit. When the mounting holes are offset by 4" and the kit is a 6" kit, the other 2 inches are made up from the strut lift or spring lift.

JBA HD High Caster Upper Control Arms for Toyota Tacoma, 4Runner, FJ Cruisers, Lexus GX470, Lexus GX460 (1 to 3.5 inch lift)

$790.00
PRE-ASSEMBLED KIT

JBA STD HC Upper Control Arms for Toyota Land Cruiser 250 2024 + (1 to 3.5 inch lift)

$608.00
PRE-ASSEMBLED KIT

Spring Lift or Leveling Kit [1 to 3.5-inch lift]
Spacer Lift, Leveling kit, and Spring lift kit

These kits cause the upper arms to angle downward toward the ball joints. The Leveling kit or strut lift removes the factory rake angle by lifting the front level with the rear of the vehicle.

Spring kits remove the factory rake angle and lift the rear of the vehicle about 1.5" - 2.5"

Spring Lift with Cradle Drop Kit
Spring lift kit with Cradle Drop Kit

These kits cause the upper arms to angle downward toward the ball joints. The cradle drop lift, cross-member drop, or drop bracket lift kit with spring kits.

Example: 4" cradle drop lift with a 2" spring/coil over lift = 6" lift kit. 6" cradle drop lift with a 2" spring/coil over lift = 8" lift kit. When the mounting holes are offset by 4" and the kit is a 6" kit, the other 2 inches are made up from the strut lift or spring lift.

JBA STD HC Upper Control Arms for Toyota Tacoma 2024 (1 to 3.5 inch lift)

$608.00

A Summary of the Benefits

1

Ball joints are mounted on an angle to line up with steering knuckle
No more premature ball joint failure!
2

Replaceable ball joints
You can replace the ball joint for under $70.00 per control arm.
3

Factory front end alignment
No premature tire wear.
4

Red powder coat finish
Your friends can see you invested in custom arms for your vehicle
5

Heavy duty tubing
Long lasting off road durability.
6

CNC manufactured parts
Precision and consistent parts every time!
7

Manufactured in USA
Made by Americans for ALL!!

Discover the Power of JBA Upper Control Arms for Lifted Toyota Off-Road Vehicles

Hello off-road enthusiasts! Today, we're going to explore an innovative product that's been making waves in the off-road community - the JBA Upper Control Arms. These aren't just any control arms; these beauties are specifically designed for lifted Toyota vehicles, including the Tacoma, 4Runner, FJ Cruiser, Sequoia, and Tundra. So, strap in, because we're about to dive deep into the world of this game-changing product.

Introduction to JBA Upper Control Arms
JBA Offroad is a brand synonymous with high-quality UCAs for off-roading vehicles. The JBA Upper Control Arms are precision-engineered to offer improved handling, increased articulation, and a smoother ride for your off-road beast. But what makes them shine is their compatibility with lifted Toyota models. If you've given your Toyota that extra height, these control arms are a must-have.

Features That Set Them Apart
The JBA Upper Control Arms come packed with features that give them a competitive edge. Here's the breakdown:

Material: Crafted from 1026 DOM A513-5 domestic tubing, these control arms are far stronger and more durable than OEM control arms. They're built to withstand the rough and tumble of off-roading with ease.
Design: These control arms feature a unique 90° range of motion ball joint construction. This means more articulation and improved off-road capabilities - perfect for those tricky terrains.
Patented EZ Lube Bushings: Remember the struggle of maintaining your bushings? Well, those days are over thanks to JBA's patented EZ Lube bushings. They come with grease ports and pressure relief valves, which not only make maintenance a breeze but also extend the lifespan of your bushings.
Caster Correction: Lifted vehicles often lose some caster, which can affect handling. JBA Upper Control Arms come with built-in caster correction to improve your vehicle's handling and restore lost caster.
Powder Coating: These control arms are coated with Tiger Drylac Bengal Red powder coat, providing high durability, corrosion resistance, and a visually appealing finish.

Delving into the Technical Specifications
Now that we've covered the features, let's delve into the technical specifications:

Weight: The JBA Upper Control Arms weigh approximately 19 lbs. They're light enough for easy handling but heavy-duty for off-roading.
Tubing Dimensions: These control arms feature 1.06" OD x 0.75" ID or 1.313" OD x 1.00" ID tubing - the perfect size to ensure strength and durability.
Installation Time: You won't have to spend your entire day installing these control arms. The process typically takes between 1 to 3 hours.

Installation Guide
While the installation of the JBA Upper Control Arms is relatively straightforward, following the correct steps is crucial for optimal performance and safety:

Lift the Vehicle: Use a suitable lift or jack to raise the vehicle and provide enough clearance to work underneath.
Remove OEM Control Arms: Disconnect any necessary components, such as the ball joints and bushings, and remove the OEM control arms.
Install JBA Upper Control Arms: Align the JBA control arms with the mounting points and secure them using the provided hardware. Follow the manufacturer's instructions for torque specifications.
Grease Bushings: Apply grease to the EZ Lube bushings using a grease gun. Remember, regular greasing every 3000 to 5000 miles or during oil changes is essential.
Inspect Thoroughly: Double-check all connections, ensure proper alignment, and verify that all components are securely fastened.
Test Drive: Take your vehicle for a test drive to ensure everything is working as expected and feel the improvements in handling and ride quality.
Proper alignment: Take your Toyota to your local alignment specialist to get a proper front-end alignment to the JBA lifted spec in the control arm installation book.

Benefits for Your Lifted Toyota
With JBA Upper Control Arms installed in your lifted Toyota Tacoma, 4Runner, FJ Cruiser, Sequoia, or Tundra, you can expect:

Improved Off-Road Performance: Increased articulation means better wheel travel and improved off-road capabilities - perfect for challenging terrains.
Enhanced Handling: The built-in caster correction improves steering response and stability, especially at higher speeds.
Smoother Ride: The superior strength and design of the JBA control arms contribute to a smoother and more comfortable ride, reducing vibrations.
Durability: High-quality materials and powder coating finish ensure the longevity of these control arms, even in harsh conditions.
Easy Maintenance: The EZ Lube bushings make maintenance easy and quick, ensuring optimal performance of the control arms.

User Reviews
Many users have reported significant improvements in off-road performance and handling after installing the JBA Upper Control Arms. Here are some customer comments:

“Arms display quality from end to end. Impeccable fit and finish.”
“These things are made with exceptional attention to detail and quality.”
“Installation instructions were on point and installation went smoothly.”
“The changed geometry by installing this product produced a great alignment which smoothed out the ride considerably.”
“You guys go all out to make sure the customer is happy. I really appreciate the attention and courtesy that you gave me. Emails, phone calls and texts. You guys are awesome and I’ll continue to buy more from you. I have already recommended you to my buddies.”

The Final Verdict
Considering the features, technical specifications, and user reviews, it's clear that JBA Upper Control Arms offer a reliable and performance-enhancing upgrade for lifted Toyota Tacoma, 4Runner, FJ Cruiser, Sequoia, and Tundra off-road vehicles. Whether you're new to off-roading or a seasoned enthusiast, these control arms are definitely worth considering. They not only improve off-road capabilities but also enhance handling and provide a smoother ride.

So, if you're looking to maximize the potential of your lifted Toyota vehicle, give JBA Upper Control Arms a test drive. You won't be disappointed!
